OptiLinker
OptiLinker
| Item | Fiber Optical Modules |
| Part Status | Active |
| Form Factor | QSFP |
| Max Data Rate | 103.125Gbps (4x 25.78Gbps) |
| Max Cable Distance | 70m@OM3/100m@OM4 |
| Wavelength | 850nm |
| Connector | MTP/MPO-12 |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Transmitter Type | VCSEL 850nm |
| TX Power | -8.4~2.4dBm |
| Receiver Sensitivity | <-10.3dBm |
| Powerbudget | 1.9dB |
| Receiver Overload | 2.4dBm |
| Power Consumption | ≤2.5W |
| Extinction Ratio | >3dB |
| DDM/DOM | Supported |
| Warranty | 5 Years |
| Sample | Available |
| Protocols | IEEE 802.3bm, QSFP28 MSA, SFF-8665, SFF-8636, RoHS, CPRI, eCPRI |
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE, and UL, owning advanced manufacturing facilities and test equipment imported from abroad.
Our company was established in 1997, and we have around 2000 staff at present. With an abundant production capacity of 3000K per month, we are able to deliver products within a short timeframe.
Moreover, we provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also offers high-speed optical interconnection solutions for cloud computing and ultra-broadband networks. With the latest optoelectronics technologies, we develop, manufacture, and sell products around the world.
