| Item | Value |
|---|---|
| Model Number | LPJK9029A159NL |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications-Lan | 5G Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Yellow&Green - Yellow |
| Number of Cores per Jack | 8 |
| Shielding | Shielded |
| Number of Ports | Single Port |
| Features | Board Guide |
| Tab Direction | Down |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | 0°C ~ 70°C |
This connector is specifically designed for local area networks (LAN), with optimized support for 5G Base-T applications and AutoMDIX functionality.
It utilizes a Through Hole mounting type, features a 90° Angle (Right) orientation, and supports solder terminations with a Down tab direction.
This connector supports Power over Ethernet (PoE) up to 50 Watts and achieves data transmission rates of up to 10 Gbit/s.
It complies with IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, and the upcoming IEEE 802.3bt standards.
The connector is designed to function reliably in temperature environments ranging from 0°C to 70°C.
The standard configurations ship with 110 pieces per tray, packing 550 pieces per carton. Box sizes are 34.5*34.5*27cm with a total weight of 5.5KGS.
